Mobile Trailer Vacuum Transformer Oil Purifier Application
The Mobile Transformer Oil Regeneration System has been specially designed for on site use to completely regenerate insulating oils in energized or d-energized transformers. The system provides regular oil purification such as degassing, drying and particulate removal but its main application is in the removal of acidity, sludge, other soluble oil decay products and discoloration. This is accomplished by the use of high vacuum degasification technology and particulate filters combined with our special brand of earth. The Model is mounted on a leak proof base and can be installed and operated on a trailer.
HOPU Transformer Oil Dehydration System Features
1. Mobile (trailer) type, completely closed structure, waterproof, dust proof, move easy.
2. Installation of car tyres, Bridge shock absorber, braking system and steel welding of entire trailer guarantee 60km/h speed.
3. Dealing with unqualified insulating oils, rapidly remove water, gas, particles from oil
4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies
5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable.
6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely.
7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically.
HOPU Mobile Oil Purifier Advantages
It can not only removing the water, gas and impurities which mixed in the oil, but also can improve many values reach to the national standard such as the acid value, PH value. Meanwhile, it improves the voltage-withstand value through filtering the polarity materials like free carbon, deep oxides and so on.
We warmly welcome if you want an on-the-point inspection of our factory, you will see various models in our factory and will get professional knowledge of our machine with detailed explanation of our experienced engineer. We also can offer custom solution as per special requirement.
HOPU trolley mounted vacuum transformer oil purifier technical Parameters
| HOPU Flow Rate | L/H | 1800 | 3000 | 6000 | 9000 | 12000 | 15000 | 18000 |
| Working Vacuum Degree | MPa | -0.08 ~ -0.099 |
Working
Discharge Pressure | MPa | ≤ 0.3 |
Temperature
Control Range | ºC | 20 ~ 80 |
| Operation Temperature | ºC | 40 ~ 70 (65ºC is best) |
| Power Supply |
| 380V, 50Hz, 3 phases (or as per your requirements) |
Working hours
without Trouble | Hour | 4000 |
| Continuous Working Hours | Hour | 150 |
| Ambient Temperature |
| -25 ~ 55ºC |
| Working Noise | dB(A) | 65 ~ 90 |
Heating Power
(adjusted available) | KW | 30 | 36 | 48 | 60 | 72 | 80 | 120 |
| Total Power | KW | 35.5 | 42 | 52.5 | 68 | 82 | 93 | 135 |
| Inlet/Outlet | mm | φ25 | φ32 | φ42 | φ50 | φ50 | φ60 | φ60 |
| Gross Weight (KGS) | Machine Part | 600 | 830 | 1190 | 1350 | 1490 | 1600 | 1950 |
| Trailer Parts | 380 | 430 | 500 | 570 | 640 | 700 | 800 |
Dimension
L×W×H (mm) | Machine Part | 1450
×1050
×1860 | 1710
×1350
×2150 | 1900
×1420
×2190 | 1940
×1480
×2220 | 2120
×1500
×2240 | 2150
×1700
×2350 | 2300
×1850
×2460 |
| Trailer Parts | 2700
×1760
×1010 | 2760
×1860
×1050 | 2900
×1900
×1060 | 3010
×1920
×1060 | 3020
×1940
×1070 | 3050
×1980
×1090 | 3090
×2000
×1120 |
Note: 1. The dimension and weight will be changed with changing of technical specs.
2. All the specs can be customized according to client's requirements.
Oil Result after Mobile Transformer Oil Filtration Machine
| Moisture (Water Content) | ≤ 3 ~ 5 PPM |
| Gas Content | ≤0.01% (Vol) |
| Impurities Degree (Filtration precision) | ≤ 1 ~ 5 micron (no free carbon) |
| Breakdown Voltage (Dielectric) | ≥70 KV |
| Flash Point | ≥145ºC |
| Cleanliness | ≤NAS 1638 Grade 6 |
HOPU specialized in waste oil treatment machine, which can purify and regenerate all types of oil such as engine oil, used machinery oil, hydraulic oil,transformer oil,turbine oil, insulating oil,switch oil, compressor oil, motor oil, mediate-load gear oil, cooler oil, steel rolling oil,quench oil, flash swift quench oil, etc. in mine,metallurgical industry, machinery, chemical industry,rubber industry, instrument, traffic, petroleum drilling and exploring, construction ceramics etc.
