Product Description
HOPU Mobile box-type mobile oil filter machine Application:
1.Cleaning and filtration of a large amount of waste industrial oil or fluids
2.Filtration of high solid content of waste oil
3.Bypass filtering in the working hydraulic lubricating systems.
4.Filtering while refueling the hydraulic lubricating system.
5.Recycling filtration before the hydraulic lubricating system starts operating.
6.Improve hydraulic lubricating system cleanliness.
Box type oil filtering machine technical specs
Flow rate(L/min) | 32 | 50 | 100 | 150 | 200 |
Pressure(Mpa) | 0.6 | ||||
Pressure loss(Mpa) | ≤0.01 | ||||
Coarse filtration accuracy(μm) | 180、120、80 | ||||
First level coarse filter(μm) | 5、10、20 | ||||
Second level precision filter(μm) | 3 | ||||
Alarm differential pressure(Mpa) | 0.2 | ||||
Recommended viscosity(CST) | 10-160 | ||||
Voltage | AC220V,380V,415V、50HZ,60HZ, 1,3 PHASE | ||||
Motor power | 0.75 | 1.1 | 2.2 | 3.0 | 5.5 |
Weight(Kg) | 220 | 280 | 360 | 480 | 600 |
Dimensions (L*W*H) | 950*560*900mm | 1100*660*1000mm | |||
Note: Filtration accuracy and other specs can be designed |
1.The whole machine is covered by a fine case to protect device components from external contamination, and it enables the device to be used in the high standard working environment.
2.The oil filtration machine is equipped with a dedicated motor-driven gear pump, which has characteristic of low-noise, good self-priming and smooth operating.
3.The overflow protection detector in high-pressure pipeline in the device can effectively protect the hydraulic lubricating system.
4.The thermal relay sensor will protect the machine from overload and damage of service life.
5.The primary coarse filter on the suction port protects the pump and helps the main filter with longer working life.
