Explosion Proof Coalescence Separation Diesel Oil Purifier Introduction
Mobile explosion-proof coalescence separation diesel oil purifier removes free & emulsified water plus solid particles from diesel without heating, for hazardous flammable sites including mining, oil depots, offshore platforms, diesel generator stations and petrochemical plants.
This explosion-proof coalescence separation diesel oil purifier is a fuel polishing system built for explosive hazardous zones. It adopts coalescing & separating filter elements to capture micro water droplets and solid contaminants inside diesel fuel, achieving continuous dehydration and particle filtration without heating. The complete electrical system including touchscreen PLC controller, motor and sensors is explosion-proof certified. The quick-open pressure vessel enables fast filter element replacement. Mounted on wheeled mobile skid, it supports on-site fuel purification for multiple high-risk industries.
HOPU TYB Series Diesel Oil Purifier Feature
• Product Type: Explosion Proof Coalescence Separation Diesel Oil Purifier
• Core Technology: Coalescence separation filtration, non-heating dehydration
• Core Function: Remove emulsified water, free water, sludge and solid particles from diesel
• Electrical Feature: Full explosion-proof electrical assembly, EX control cabinet with emergency stop protection
• Control System: PLC touch screen, real-time pressure monitoring and visualized workflow
• Structure: Mobile caster skid, quick-open tank for easy filter element maintenance
• Consumables: Matching coalescing filter & separation filter cartridges
• Working Medium: Diesel fuel, light fuel oil
HOPU TYB Series Diesel Oil Purifier Technical Data
|
Name
|
Unit
|
TYB-10
|
TYB-30
|
TYB-50
|
TYB-100
|
TYB-150
|
TYB-250
|
TYB-300
|
|
Flow rate
|
L/hr
|
600
|
1800
|
3000
|
6000
|
9000
|
1500
|
18000
|
|
Working Pressure
|
Mpa
|
≤0.3
|
|
Working Noise
|
dB(A)
|
≤65
|
|
Power
|
kW
|
0.75
|
1.1
|
1.5
|
2.2
|
3
|
4
|
5
|
|
Net Weight
|
kg
|
250
|
350
|
400
|
450
|
500
|
600
|
700
|
|
OverallDimensions
|
L
|
mm
|
1000
|
1100
|
1150
|
1200
|
1250
|
1400
|
1500
|
|
W
|
mm
|
600
|
650
|
700
|
800
|
1000
|
1200
|
1400
|
|
H
|
mm
|
1400
|
1450
|
1500
|
1550
|
1600
|
1650
|
1700
|
HOPU TYB Series Diesel Oil Purifier Application Industries & Sites:
✅ Mining: On-site diesel purification for mining trucks, drilling rigs and underground mining equipment
✅ Oil depots & fuel terminals: Polish stored diesel, eliminate water and sediment inside fuel storage tanks
✅ Diesel power stations: Fuel conditioning for backup diesel generator sets
✅ Offshore & marine projects: Marine diesel filtration for vessels, offshore oil platforms and coastal fuel stations
✅ Petrochemical plants: Diesel treatment in explosive-risk chemical workshops
✅ Large construction & engineering sites: Fuel cleaning for heavy construction machinery and mobile fleets
✅ Emergency & military fuel storage: Maintain diesel quality for emergency fuel reserves in classified hazardous areas
Advantages: Low running cost, compact integrated design, stable continuous operation, no heating required
