What are Some Effects of Impure Insulation Transformer Oil?
Ø A decrease in oil efficiency
Ø Corrosion of the moving and mechanical components
Ø A reduction in the load-carrying capability
Ø Degradation from microbial elements
Ø An explosion in the crankcase
Ø A high production rate of acid in piston engines
Ø High maintenance costs
Ø A reduction in machine performance
Transformer Oil Centrifuging Purifier Aplicable scope
This transformer oil centrifugal purifier performs the function of upgrading and reconditioning of insulating transformer oil by means of dehydration, degassing,and removing impurities such as dust,gas,sludge,water etc. The major operation is heating, filtering. After recycling, it can boost performance of transformers, circuit breakers, mutual inductors, cable and capacitors which have insulation system.
HOPU ZYD series Double Stage Vacuum Transformer Oil Centrifuge Purifier specialize in purifying transformer oil, insulating oil of high voltage and super high voltage transformer.
1.For maintenance of large scale power substation transformers, rapid and deep treatment of new transformer oil, imported insulation oil. As well as vacuum filtering and purifying of mutual inductor oil, capacitor oil, refrigerator oil.
2.Especially suitable for purifying of large scale power transmission units higher than 110KV and transformers of main state grid.
3.It is widely used in power plants, power stations, power companies, metallurgy, petrifaction, machinery, transportation, railways ect. industries, especially at plateau area higher than 500 meters sea level.
Transformer Oil Centrifugal Purifier Features
GIS connection available
Digital vacuum degree management
Anti-absorption
Machine can start fast
Strong vacuum pumping capacity
Stable performance
Easy operation
Insulation Oil Centrifugal Purifier Technical Parameter
| Flowrate | L/min | 30 | 50 | 80 | 100 | 150 | 200 | 300 |
| Vacuum Range | MPa | -0.07~0.099 |
| Working Pressure | MPa | ≤0.5 |
| Working Temperature | ℃ | 30~80 |
| Working Noise | dB(A) | 60 | 65 | 70 | 75 | 78 | 80 | 85 |
| Heating Power | KW | 30 | 36 | 48 | 60 | 81 | 90 | 120 |
| Total power | KW | 35 | 42 | 65 | 66 | 88 | 102 | 133 |
| Inlet(outlet)Diameter | mm | Φ32 | Φ32 | Φ42 | Φ42 | Φ48 | Φ60 | Φ76 |
| Net Weight | KG | 650 | 850 | 900 | 1100 | 1400 | 1800 | 2000 |
| Overall Dimensions | L | mm | 1200 | 1250 | 1500 | 1600 | 1700 | 1750 | 1800 |
| W | mm | 920 | 950 | 1100 | 1150 | 1200 | 1250 | 1300 |
| H | mm | 1450 | 1500 | 1700 | 1800 | 1800 | 1900 | 2000 |
Oil Centrifugal Purifier Performance Index
| Item | Index after processing |
| Breakdown Voltage | ≥75KV |
| Content of water | ≤3ppm |
| Content of gas | ≤0.1% |
| Content of Impurity Grain | ≤3μm |
| Flash point | ≥135℃
|
HOPU Oil Filtration Manufacturer is professional for different oil filtration solutions, HOPU can supply the best quality oil purification machine to you. Our price is competitive and we take responsibility to any quality uncertainty. We produce our products using only high quality raw materials and employ many skilled employees and technicians. For more product specification please contact us by email for a detailed catalog. Our factory can provide the most preferential profit to customers all over the world with competitive prices and high quality items.
FAQ
Are you a manufacturer or trading company?
Manufacturer.
HOPU has three workshops to design different product
Workshop 1 is for domestic and standard product design for oil purifier and oil testing unit
Workshop 2 is for double vacuum chamber or high vacuum oil purifier design
Workshop 3 is for customized designs and OEM order
How to ensure the security of purchase from HOPU ?
HOPU is a legal and customs registered enterprise, our products are legal in global customs. Quality and and after sales service can be guaranteed
